Toro | SKU: 74024

Toro Z Master 4000 HDX Pro XL | 72" Deck | MyRIDE | 35hp Kawasaki | Zero Turn Mower | 74024

$15,699⁰⁰

Taxes and shipping calculated at checkout.

Pickup available at MSM - Clermont

Usually ready in 4 hours

WARNING: This product can expose you to chemicals including lead and lead compounds, which is [are] known to the State of California to cause cancer. For more information go towww.P65Warnings.ca.gov

Unleash power, comfort, and confidence like never before with the 72-inch Z-Master 4000 HDX with MyRIDE® Suspension System. Dominate any job with the relentless 35 HP* Kawasaki FX1000 engine and legendary TURBO FORCE® cutting deck, reinforced with heavy-duty commercial-grade hydros, and supported by the 26-inch Voodoo Trac™ tires. Plus, with the hour meter, USB ports, phone holder, and cup holder, you’ll have everything you need to conquer the day in comfort.

Survey the task from a higher-vantage-point with the 26" Voodoo Trac™ drive tires.
Powerful illumination for after-hours work with LED headlights.
Keep your phone and drink at arm's reach.
The 7 gauge TURBO FORCE® deck with the I-beam front end is built to last and backed by our impressive warranty.
Keep tabs on time and keep devices powered up with the hour meter and USB ports.
Horizon360^® Business Management Software. Work More Efficiently. Run More Profitably.

Specifications

Blade Design	0.25 in. / 0.635 cm thick heat-treated steel
Blade Tip Speed	18,500 ft/min / 5,638 m/min
Box Dimensions	91 in. x 82 in. x 52 in. / 231.1 cm x 208.3 cm x 131.1 cm
Caster Tires	15 in. x 6.5 in. - 6 in. (38.1 cm x 16.5 cm - 15.2 cm) Flat-Free Semi-Pneumatic
Clutch	Electromagnetic
Comfort Platform	MyRIDE^® Suspension System
Deck Design	72" (183 cm) 7-Gauge High-Strength Steel TURBO FORCE®
Deck Size	72 in / 183 cm
Discharge Chute	Rubber
Drive Tires	Voodoo Trac 26 in. x 12 in. - 12 in. (66 cm x 30.5 cm - 30.5 cm)
Engine	35 hp* Kawasaki FX1000V (999 cc) with Heavy-Duty Donaldson® Canister-Style Air Cleaner
Engine Brand	Kawasaki
Engine Displacement (cc)	999 cc
Engine Horsepower	35 hp
Foot Operated Height of Cut	Standard
Forward Ground/Transport Speed	Up to 12.0 mph / 19.3 kph
Fuel Capacity	10 gal. / 37.8 L / 40 Qt.
Fuel Type	Gasoline
Height of Cut	1.5 - 5.5 in. / 3.8 - 14.0 cm in 0.25 in (0.6 cm) increments
Hour Meter	Standard
Product Type	Zero Turn Mowers
Roll-Over Protection (ROPS)	Folding; Standard
Seat	Deluxe Seat with Armrests
Spindle Bearings	Maintenance-free
Spindle Housing	9 in / 22.9 cm Diameter Cast Aluminum
Start Type	Electric
Steering Controls	1.4" (3.6 cm) Diameter Grips; Adjustable, Dampened
Transmission	ZT-5400 Integrated Pumps and Wheel Motors
Weight	1,448 lbs / 656.8 kg

Disclaimer

*The gross horsepower of these engines was laboratory rated at 3,600 RPM by the engine manufacturer in accordance with SAE J1940 and SAE J1995. As configured to meet safety, emission and operating requirements, the actual engine horsepower on this mower may be significantly different.

Maintenance Service Interval	Maintenance Procedure
After the first 8 hours	For Kawasaki engines—change the engine oil. For Kohler engines—change the engine oil.
After the first 100 hours	Check the parking brake adjustment. Change the hydraulic-system filters and fluid.
Before each use or daily	Check the safety-interlock system. For Kawasaki engines—check the engine-oil level. For Kohler Engines—check the engine-oil level. Clean the engine screen, engine-oil cooler, and the area around the engine. Clean around the engine-exhaust system. Check the seat belt. Check the hydraulic-fluid level in the expansion tank. Inspect the blades. Clean the suspension system.
After each use	Clean the mower deck.
Every 50 hours	Check the spark arrester (if equipped). Check the tire pressure.For machines with pneumatic tires only. Inspect the belts for cracks and wear.
Every 100 hours	Lubricate the mower deck-lift pivots. For Kawasaki engines—change the engine oil(more often in dirty or dusty conditions). For Kawasaki engines—replace or clean and gap the spark plug. For Kohler Engines—change the engine oil(more often in dirty or dusty conditions).
Every 150 hours	For Kohler engines—inspect the primary filter(more often in dirty or dusty conditions).
Every 200 hours	For Kawasaki engines—change the engine-oil filter(more often in dirty or dusty conditions). For Kohler Engines—change the engine-oil filter(more often in dirty or dusty conditions). For Kohler Engines—check the spark plug(s).
Every 250 hours	For Kawasaki engines—replace the primary air filter(more often in dirty or dusty conditions). For Kawasaki engines—check the safety air filter(more often in dirty or dusty conditions).
Every 300 hours	For Kawasaki engines—Check and adjust the valve clearance. See an Authorized Service Dealer. For Kohler engines—replace the primary air filter(more often in dirty or dusty conditions). For Kohler engines—check the inner air filter(more often in dirty or dusty conditions).
Every 400 hours or yearly, whichever comes first	After the initial change—change the hydraulic-system filters and fluid when using Toro® HYPR-OIL™ 500 fluid(change it more often under dirty or dusty conditions).
Every 500 hours	For Kawasaki engines—replace the safety air filter(more often in dirty or dusty conditions). For Kohler Engines—replace the spark plug(s). Replace the fuel filter(more often in dusty, dirty conditions). Check the parking brake adjustment.
Every 600 hours	For Kohler engines—replace the inner air filter.
Monthly	Check the battery charge.
Yearly	Repack the caster-wheel bearings(more often in dirty or dusty conditions). Greasing the caster-wheel hubs.
Yearly or before storage	Paint chipped surfaces.

Description

Survey the task from a higher-vantage-point with the 26" Voodoo Trac™ drive tires.
Powerful illumination for after-hours work with LED headlights.
Keep your phone and drink at arm's reach.
The 7 gauge TURBO FORCE® deck with the I-beam front end is built to last and backed by our impressive warranty.
Keep tabs on time and keep devices powered up with the hour meter and USB ports.
Horizon360^® Business Management Software. Work More Efficiently. Run More Profitably.

Specifications

Blade Design	0.25 in. / 0.635 cm thick heat-treated steel
Blade Tip Speed	18,500 ft/min / 5,638 m/min
Box Dimensions	91 in. x 82 in. x 52 in. / 231.1 cm x 208.3 cm x 131.1 cm
Caster Tires	15 in. x 6.5 in. - 6 in. (38.1 cm x 16.5 cm - 15.2 cm) Flat-Free Semi-Pneumatic
Clutch	Electromagnetic
Comfort Platform	MyRIDE^® Suspension System
Deck Design	72" (183 cm) 7-Gauge High-Strength Steel TURBO FORCE®
Deck Size	72 in / 183 cm
Discharge Chute	Rubber
Drive Tires	Voodoo Trac 26 in. x 12 in. - 12 in. (66 cm x 30.5 cm - 30.5 cm)
Engine	35 hp* Kawasaki FX1000V (999 cc) with Heavy-Duty Donaldson® Canister-Style Air Cleaner
Engine Brand	Kawasaki
Engine Displacement (cc)	999 cc
Engine Horsepower	35 hp
Foot Operated Height of Cut	Standard
Forward Ground/Transport Speed	Up to 12.0 mph / 19.3 kph
Fuel Capacity	10 gal. / 37.8 L / 40 Qt.
Fuel Type	Gasoline
Height of Cut	1.5 - 5.5 in. / 3.8 - 14.0 cm in 0.25 in (0.6 cm) increments
Hour Meter	Standard
Product Type	Zero Turn Mowers
Roll-Over Protection (ROPS)	Folding; Standard
Seat	Deluxe Seat with Armrests
Spindle Bearings	Maintenance-free
Spindle Housing	9 in / 22.9 cm Diameter Cast Aluminum
Start Type	Electric
Steering Controls	1.4" (3.6 cm) Diameter Grips; Adjustable, Dampened
Transmission	ZT-5400 Integrated Pumps and Wheel Motors
Weight	1,448 lbs / 656.8 kg

Disclaimer

Maintenance Service Interval	Maintenance Procedure
After the first 8 hours	For Kawasaki engines—change the engine oil. For Kohler engines—change the engine oil.
After the first 100 hours	Check the parking brake adjustment. Change the hydraulic-system filters and fluid.
Before each use or daily	Check the safety-interlock system. For Kawasaki engines—check the engine-oil level. For Kohler Engines—check the engine-oil level. Clean the engine screen, engine-oil cooler, and the area around the engine. Clean around the engine-exhaust system. Check the seat belt. Check the hydraulic-fluid level in the expansion tank. Inspect the blades. Clean the suspension system.
After each use	Clean the mower deck.
Every 50 hours	Check the spark arrester (if equipped). Check the tire pressure.For machines with pneumatic tires only. Inspect the belts for cracks and wear.
Every 100 hours	Lubricate the mower deck-lift pivots. For Kawasaki engines—change the engine oil(more often in dirty or dusty conditions). For Kawasaki engines—replace or clean and gap the spark plug. For Kohler Engines—change the engine oil(more often in dirty or dusty conditions).
Every 150 hours	For Kohler engines—inspect the primary filter(more often in dirty or dusty conditions).
Every 200 hours	For Kawasaki engines—change the engine-oil filter(more often in dirty or dusty conditions). For Kohler Engines—change the engine-oil filter(more often in dirty or dusty conditions). For Kohler Engines—check the spark plug(s).
Every 250 hours	For Kawasaki engines—replace the primary air filter(more often in dirty or dusty conditions). For Kawasaki engines—check the safety air filter(more often in dirty or dusty conditions).
Every 300 hours	For Kawasaki engines—Check and adjust the valve clearance. See an Authorized Service Dealer. For Kohler engines—replace the primary air filter(more often in dirty or dusty conditions). For Kohler engines—check the inner air filter(more often in dirty or dusty conditions).
Every 400 hours or yearly, whichever comes first	After the initial change—change the hydraulic-system filters and fluid when using Toro® HYPR-OIL™ 500 fluid(change it more often under dirty or dusty conditions).
Every 500 hours	For Kawasaki engines—replace the safety air filter(more often in dirty or dusty conditions). For Kohler Engines—replace the spark plug(s). Replace the fuel filter(more often in dusty, dirty conditions). Check the parking brake adjustment.
Every 600 hours	For Kohler engines—replace the inner air filter.
Monthly	Check the battery charge.
Yearly	Repack the caster-wheel bearings(more often in dirty or dusty conditions). Greasing the caster-wheel hubs.
Yearly or before storage	Paint chipped surfaces.
