Standard Feature |
Available Options |
Axles |
2 - 7,000# Premium, Cambered Axles with Quick-Lubricating Hubs |
Drop Axles (Lowers Deck Height to 24" from Ground) |
Brakes |
Forward Self-Adjusting Electric Brakes on Both Axles |
|
Suspension |
Multi-Leaf Slipper Spring w/ Equalizer |
|
Tongue |
8" Seamless I-Beam Integrated w/ Frame (10#) |
|
Coupler |
Round Adjustable Pin 2-5/16” Gooseneck Coupler |
Adjustable Pintle in Channel in Lieu of Coupler |
Safety Chains |
3/8" Grade 70 w/ Safety Latch Hook (2 ea) |
|
Jack |
Dual 12,000# Drop-Leg Jack (Side Wind) |
Dual 2-Speed Landing Gear |
Frame |
8" I-Beam (10#) |
|
Cross-Members |
3" Channel on 16" Centers |
|
Floor |
10 Gauge Smooth Steel |
|
Fenders |
9" x 72" 14 Ga. Diamond Plate Double Broke |
|
Ramps |
Not Included |
6.5’ Slide In Ramp Package |
Stake Pockets |
Stake Pockets Along Both Sides (Quantity Varies by Length) |
|
Trailer Plug |
7-Way RV |
|
Lights |
Recessed, Grommet-Mounted L.E.D. Lighting |
|
Wiring |
Sealed, Modular Cold-Weather Wiring Harness |
|
Tires |
ST235/80 R-16 Load Range E Radial Tires |
|
Bolt Pattern |
8-Lug |
|
Wheels |
Black Mod Steel |
|
Spare Mount |
Side Spare Tire Mount |
|
Spare Tire |
Not Included |
- Spare Tire & Wheel (ST235/80 R-16 LR-E)
- Spare Tire Upgrade (ST235/80 R-16 LR-G)
|
Paint Type |
Professional Finish w/ Primer Standard |
|
Paint Color |
Black |
|
Tie-Downs |
(4) 1/2" D-Rings Inside Bed to Secure Equipment Along Sides and Rear for Cargo Control |
|
Break-Away Kit |
Complete Breakaway System w/ Zip Breakaway Cable |
|
Battery |
12V Deep Cycle |
|
Charger |
5A 110V on Board Battery Charger |
|
Deck On Neck |
|
Removable Deck on the Neck- Bolt On (8' W x 6' L) |
Gate |
Rear Combo Gate (Barn Doors & Spreader Gate) |
|
J-Hooks |
Along sides and rear for Cargo Control |
|
Power |
Power Up/Power Down & Gravity Down Hydraulic Pump |
- 5 Watt Solar Charger
- Wireless Remote
|
Ram |
Self-Contained Scissor |
|
Sides |
24" Tall (10 Ga) with formed Channel Supports |
- 24" Expanded Metal Side Extensions
- 3' Solid Sheet Metal Sides
- 4' Solid Sheet Metal Sides
|
Stabilizers |
Rear Stabilizer Stands |
|
Steps |
Convenient Side-Step to Access Top Rail |
|
Storage |
Lockable Pump and Battery Box mounted between front Jacks |
|
Tarp |
Fully-Formed Tarp Shroud with Tarp & Rear Tarp Rod Holders |
|
Top Rail |
3"x 2" Rectangular Tubing |
|
Steps & Handles |
Convenient Side-Step to Access Top Rail |
|
